Technical Specification
| Power Supply | 380v 50Hz |
|---|---|
| Air Pressure | 0.5-0.8 Mpa |
| Working Area | 160 x 160 x 3200 |
| Transverse Stroke (x-axis) | 3200 mm |
| Vertical stroke (z-axis) | 300 mm |
| Operational Speed of Y-Axis | 0~15m / Min |
| Overall Dimension | 4400 x 1500 x 1800 mm |
| Power Supply | 380v 50Hz |
| Input Power | 6 kW |
| Air Consumption | 50L / Min |
| Working Position | 90, 0, 90 |
| longitudinal stroke (y-axis) | 300 mm |
| X-axis operation speed | 0~60m / Min |
| Cutting Tool Holder | ER25-8mm |
| Spindle Speed / Power | 18000 rpm / 3kW |
Equipment Features
Milling Aluminum Profile at different size of holes and grooved, Adopted Ball bearing movement device, high Precision guide liner rack and pinion, Servo motor ensure the stable movement with high precision position and operation, Adopted imported high speed main axis motor, stable rotation, low noise, strong milling ability, Intelligent integrated CNC system, concision and vivid human and Machine Interface, Easy Operation.
